G - 2 BeneVision N Series Patient Monitor Operator’s Manual

G.2 Symbols

mmHg millimeters of mercury

cmH2O centimeters of water

ms millisecond

mV millivolt

mW milliwatt

M megaohm

nm nanometer

rpm breaths per minute

ssecond

Vvolt

VA volt ampere

ohm

Wwatt

Abbreviation In Full

Symbol Explanation

－

minus

–negative

%percent

/ per; divide; or

～

＋

plus

＝

equal to

＜

less than

＞

greater than

≤ less than or equal to

≥ greater than or equal to

± plus or minus

×multiply

©copyright
