9 - 4 BeneVision N Series Patient Monitor Operator’s Manual
■ For the parameters measured and controlled by the external device, measurements and settings are
displayed after parameter labels, and settings are also enclosed in parenthesis. For example, PEEP 18 (20),
in which PEEP is parameter label, 18 is the measurement, and (20) is the setting.
NOTE
• Parameters in the Integrated Devices screen are displayed in the order of priorities. If the screen
cannot display all the selected parameters, only parameters with higher priorities are displayed.
9.6 Displaying Parameters from External Devices
This monitor can display parameters from external devices in the main screen:
■ Display waveforms from external devices in the waveform area.
■ Display labels and measurements of parameters from external devices in the numeric area.
■ Display respiratory loops of parameters from external deivices in the Loops screen.
NOTE
• When displayed in the monitor main screen, parameter labels of external devices are prefixed with
the plug sign “+”. For example, if SpO
2
is from an external device, its label is displayed as “+SpO
2
”,
and its waveform label is displayed as “+Pleth”.
• If a parameter can be obtained either from the monitor or an external device, the measured value,
waveform or loops coming fromthe monitor will be displayed preferentially.
9.6.1 Setting Waveform Properties for Parameters from External Devices
To set the waveform properties for parameters from external devices, follow this procedure:
1. Access the parameter setup menu by selecting its waveform area or numeric area.
2. Set Speed or Scale.
9.6.2 Setting Alarms from External Devices
To enable or disable the storage, display, and sound of the external device alarms of a certain priority and
category, follow this procedure:
1. From the Integrated Devices screen select Setup.
2. Select the switches as desired.
If the storage, display, or audio settings of a specific alarm are different from its category or priority, set them
individually by adding this alarm to the alarm list. To do so, follow this procedure:
1. From the Integrated Devices screen select Setup.
2. Input the alarm ID for this alarm, and select Add.
To delete a specific external device alarm, select the desired alarm ID, and select Delete.
9.6.3 Setting Parameters from External Devices for Display
To select parameters displayed in the Integrated Devices screen, follow this procedure:
1. From the Integrated Devices screen select Select Parameter.
2. Select desired parameters.
In the main screen, the numeric area of some parameters from an external device, for example the +Paw
parameter, can display multiple parameters. To select parameters for display, follow this procedure:
1. Select the numeric area of the parameter from the external device.
2. Select the Select Parameter tab.
3. Select desired parameters.
