4
03.04 Machine Operating Area
4.2 General functions and dis
p
la
y
s
4
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 4-103
X
...
9th Axis
Milling machine:
Select the axis to be traversed and
...
+
then press the "+" or "-" key.
Traverse the axes to the point of interruption.
4.2.2 Display program level
Function
If subprograms are called while a part program is running, the block
numbers for the main program and subprograms together with their
pass number (P) can be displayed.
Operating sequence
"AUTO" mode is selected in the "Machine" operating area.
When you press softkey "Program level", the window headed
"Program level" appears instead of the "Current block" window. The
softkey labeling changes to "Current block".
During execution of a part program, the block numbers for the main
program and subprograms, together with their pass number (P), are
displayed in the "Program level" window. The main level is always
visible, a nesting depth of up to 12 can be displayed.
Current
block
When you press softkey "Current block", the "Current block" window
containing the program blocks of the current part program is displayed
again.
