5
"Parameters" Operating Area 03.04
5.3 Tool mana
g
ement
5
Ó Siemens AG, 2004. All rights reserved
5-214 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Sequence of operations (loading from the "Tool list")
Tool
list
The "Tool list" is selected.
The appropriate tool is selected.
Load
Press the "Load" softkey.
The vertical softkey bar changes.
Find empty
location
Search for an empty location for a tool which has already been
created or enter the desired location and magazine number in the list.
The location found is entered under the magazine/location number.
Abort
The loading operation is not initiated.
The basic display appears.
Start
The loading operation is initiated.
5.3.6 Unload
Function
This function allows you to unload a selected tool and to save its data.
Operating sequence
Tool ma-
nagement
Select softkey "Tool management".
The "Magazine list" is displayed.
The horizontal and vertical softkey bars change.
You can unload a tool from the "Magazine list" or the "Tool list".
The sequence of operations is the same for both methods.
