2.1.6 Full standard keyboard
A full standard keyboard can be connected. However, a machine
control panel is required in addition to this keyboard.
The special function keys of the operator keyboard can also be used
with the full PC keyboard. The following table shows how the
horizontal and vertical softkeys and the special keys for the operator
panels are mapped onto the PC keyboard keys:
Softkey assignment
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12
5 Esc Insert Home Page
Up
Page
Down
Enter
Full
keyobard
with
SHIFT
vertic
soft.
1
vertic
soft.
2
vertic
soft.
3
vertic
soft.
4
vertic
soft.
5
vertic
soft.
6
vertic
soft.
8
horiz
soft.
1
horiz
soft.
2
horiz
soft.
3
horiz
soft.
4
horiz
soft.
5
horiz
soft.
6
horiz
soft.
8
without
SHIFT
Full
keyboard
without
SHIFT
vertic
soft.
7
horiz
soft.
7
End
The following table shows how the hardkeys of the MF II keyboard on
the PC are mapped onto the keys for the operator panels:
Hardkey assignment
F10F12
Home Page
Up
Page
Down
Hardkey
MFII
with
SHIFT
Hard-
key
1
Hard-
key
2
Hard-
key
3
Hard-
key
4
Hard-
key
5
Hard-
key
6
Hard-
key
8
MFII
with-
out
SHIFT
MFII-
Num Block
Hard-
key
7
F11
operator
keyboard
F10
M-
Position
Caution
The full standard keyboard does not meet the requirements (EMC) of
a SINUMERIK control. For this reason it can be used only for
installation and service purposes.
For further information about the configuration of operating keys,
please see: /IAM/, IM4 Installation and Start-Up, Chapter 5
Functions/Parameters.
