Siemens SINUMERIK 810D User Manual

4
Machine Operating Area 03.04
4.4 JOG mode
4
Ó Siemens AG, 2004. All rights reserved
4-122 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
4.4.2 Traverse the axes
Traversing velocity
The initial settings for traversing velocity and feed mode are stored in
setting data for JOG mode.
Traversing velocities are defined by the machine-tool manufacturer.
The default setting for the feedrate is mm/min.
See operating area "Parameters/Setting data/Jog data".
Operating sequence
"Jog" mode is selected in the "Machine" operating area.
Traverse the axes
Using the "Inc" (increment) function, manually traverse the selected
axis in preset increments in the appropriate direction by pressing an
"Axis key" repeatedly:
VAR
· [.] Variable increment can be set via softkey "Inc" (see
Subsection 3.2.5).
1
...
10000
· [1], [10], ..., [10000] fixed increment
+X
...
X
Turning machine:
Press the "Axis" keys.
If necessary, set the speed with the override selector.
Rapid
If you press "Rapid traverse override" at the same time, you can
traverse the axis in rapid traverse mode.
X
...
9th Axis
Milling machine:
Select the axis to be traversed and
+
then press the "+" or "-" key.
Feedrate and rapid traverse override switches can be operative.
One or several axes can be selected at the same time (depending on
PLC program).
