7
"Services" Operating Area 03.04
7.6 Mana
e data
7
Ó Siemens AG, 2004. All rights reserved
7-390 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Loadable compile
cycles, SW 6.3 and
higher
You can use the HMI user interface to transfer the loadable compile
cycles (CC) easily from an NC card to the NCK control. Further
storage locations are any external drive, such as a disk drive, or
network drives 1 to 4. This storage location appears in the Service
operating area under "Manage data".
You can also use the SinuCom NC or SINUCOPY-FFS
commissioning tool to copy the compile cycles onto the control.
Load CC
Each time the NC is booted, all loadable compile cycles with the
extension .ELF, which are available in the /_N_CCOEM.DIR directory,
are automatically loaded into the NCK system software. Loadable
compile cycles are always loaded on an NCU reset.
For a detailed description of how to install compile cycles, please see:
/FB3/, TE0 Installation and Activation of Loadable Compile Cycles.
7.6.4 Copy/paste
Function
You can copy
1. A single file,
2. Several files or
3. A complete directory.
Copy CC
Following a reset, the optionally available compile cycles are stored
on the NCU in the Flash File System (FFS) in directory
/_N_CCOEM.DIR and, in SW 6.3 and higher, can be copied
selectively from/to an external drive, disk or NC card.
It is thus possible to archive individual compile cycles.
The "Insert" function is available in addition to "Copy".
You can display any existing compile cycles in the Diagnosis
operating area under Service displays/Version/Compile cycles.
