Siemens SINUMERIK 810D User Manual

5
03.04 "Parameters" Operating Area
5.5 Settin
g
data
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-239
5.5.6 Other types of setting data
Function
All the setting data in the control are displayed in tabular form sorted
according to general (i.e. NCK-specific), channel-specific and axis-
specific setting data. The table contains both the setting data on the
vertical softkeys such as working area limitation, Jog data etc., as well
as special setting data such as software cam, oscillation, compensa-
tion etc.
Operating sequence
Setting
data
Select softkey "Setting data".
The vertical softkey bar changes.
Display setting data:
Misc.
Select softkey "Misc.".
The horizontal and vertical softkey bars change.
Select the type:
General
SD
· The window "General setting data ($SN_)" appears.
Channel-
specific SD
· The window "Channel-specific setting data ($SC_)" appears.
Axis-
specific SD
· The window "Axis-specific setting data ($SA_)" appears.
The current setting data of the corresponding type $SN_, $SC_or
$SA_ are displayed.
You can page up and down using the "Page" keys.
Find setting data:
Find
Enter the setting data you wish to find in the "Find" window (initial ID
is sufficient).
Find next
If several setting data have the same initial identifier, you can display
other setting data by selecting softkey "Find next".
Change setting data:
Position the cursor bar on the appropriate input field and enter a new
value.
