4
03.04 Machine Operating Area
4.2 General functions and dis
p
la
y
s
4
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 4-107
Other information
Every G group has a fixed location.
The group number (no.) and the current G function of the G groups
are displayed only if a G function is active.
References
/PG/Programming Guide Fundamentals
Status display for
swivel data
(NCK SW 6.3 and higher)
Requirement:
The swivel function (CYCLE800) has been set up by the machine
manufacturer.
The active swivel data record (orientable toolholder TOOLCARRIER)
is displayed concurrently with the transformations.
The following values are displayed:
TCARR = 1 .. n* *n max. number of set up swivel
data (TOOLCARRIER) that is active.
References
/PGZ/Programming Guide Cycles: Chapter 3 "Swiveling"
4.2.6 Display auxiliary functions
Function
Auxiliary functions active in the selected channel can be displayed.
Operating sequence
"AUTO"/"MDI"/"Jog" mode is selected in the "Machine" operating
area.
Display
Aux. fct.
The "Auxiliary functions" window appears on the screen.
Up to 5 M functions and 3 H functions can be displayed.
