2
Operator Components/Sequence of Operations 03.04
2.5 Screen la
out
2
Ó Siemens AG, 2004. All rights reserved
2-48 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
11 Work pane, NC code and operating data
The work pane (program editor) and NC data (feedrate, tool)
available in the selected operating area are displayed here.
From software Version 6.2
The unit for positional data is preceded by the diameter symbol Æ
in the work pane if the axis is currently the transverse axis and if
the tool coordinate system is set. If diameter programming is
disabled with DIAMOF, the symbol preceding the unit is no longer
visible.
12 Dialog line with operator information
Here operator information is displayed for the selected function (if
available).
13 Focus
The selected pane is highlighted by a frame. The pane title is
displayed in reverse highlighting. Data entered on the operator
panel front apply to this window.
16 Recall function, i.e. key ^ is active
17 ETC. function, i.e. > key is active
18 Horizontal softkeys
19 Vertical softkeys
The softkey functions available in the selected operating area are
displayed in the horizontal/vertical softkey bar (corresponding to F1
to F8 on the full keyboard).
Other Information
The screen layout may differ slightly from the layout displayed above
depending on the screen size or resolution used.
2.5.2 Global machine status display
1 Operating areas The currently selected operating area is displayed (Machine,
Parameters, Program, Services, Diagnosis, Start-Up).
2 Channel status The current channel status is displayed:
- Channel reset
- Channel interrupted
- Channel active
