03.04 Operator Components/Sequence of Operations
2.8 Job list
2
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 2-83
COPY /SPF.DIR/PART1.* CG=MILL2
(Copies all files with one name from one directory e.g.
PART1.* from subroutines (SPF.DIR) to one channel group,
i.e. in all NCs which have channels of this group
assigned to them)
COPY /MPF.DIR/* CH=CHANNEL22
(Copies all files from one directory, e.g. all files from part
programs (MPF.DIR) to the NC which is assigned this
channel.)
2.8.2 Example of a job list with two-channel 1:1 connections
Example
If only channel1 and channel2 on NCU1 (1:1 link) were involved in
machining of the workpiece, then the most suitable job list structure
would be as follows:
LOAD /MPF.DIR/Gen.MPF
LOAD /WCS.DIR/Part1.WPD/WpdGen.MPF
LOAD /WCS.DIR/Part1.WPD/ Channel1.MPF
LOAD /WCS.DIR/Part1.WPD/ Channel1.INI
LOAD /WCS.DIR/Part1.WPD/ K12.MPF
LOAD /WCS.DIR/Part1.WPD/ Channel2.MPF
LOAD /WCS.DIR/Part1.WPD/ Channel2.INI
LOAD /WCS.DIR/Part1.WPD/ K22.MPF
SELECT /WCS.DIR/Part1.WPD/Channel1.MPF CH=1
SELECT /WCS.DIR/Part1.WPD/Channel2.MPF CH=2
The destination is not specified for loading in a 1:1 link, the current NC
is the default.
