5
03.04 "Parameters" Operating Area
5.6 Work offset
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-247
5.6.4 Display active settable work offset
Function
The active settable work offsets (selected from part program or MDI)
can be displayed.
Operating sequence
Work
offset
Go to...
Select softkeys "Work offset" and "Go to ...".
The vertical softkey bar changes.
Active
settable
The "Active settable WO" window opens.
You can alter these values if necessary.
/PGA/, Programming Guide, Advanced
Overview
An overview shows all values of the active work offset and offsets (no
changes possible) including a selection of tool data (T number, D
number, etc.). The basic work offset and the settable work offset are
displayed as the sum.
Axis +
Overview
Change
active WO
Work
offset
R
variable
Setting
data
User
data
Zero
offset
MPF.DIR
TEST.MPF
Channel active
AUTO CHAN1Parameter
Axis -
:
Übersicht der aktiven Nullpunktverschiebungen und Korrekturen
Z
Z1 [mm]
000.000
000.000
0.000
0.000
0.000
000.000
0.000
0.000
1.000
200.000
000.000
X
X1 [mm]
000.000
000.000
399.000
1.000
0.000
1.000
0.000
0.000
100.000
500.000
100.000
0.000
34
Y
Y1 [mm]
000.000
000.000
0.000
0.000
100.000
100.000
0.000
0.000
1.000
400.000
100.000
0.000
D-Nr. 2
Ebene G17
Überlagerte Bewegung
DRF-Verschiebungen
Externe NV
Summe NV
Akt. Werkzeug
Achse
Istwert[MKS]
Istwert[ENS]
grob
fein
Drehung [Grad]
Maßstab
Spiegeln
Längen
Radius
Istwert [WKS]
T-Nr.
Program running
