03.04 "Startup" Operating Area
9.2 User views
9
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 9-445
9.2 User views
Function
Start-up
User
views
User views are user-specific collections of machine data saved under
one name. They are used to call all relevant machine data in a certain
operating state if necessary from various areas to process in the
display.
Edit
view
Insert
data...
<<
Insert
text ...
Delete
line
Up
/
Down
Properties
The vertical softkey bar changes.
In the "Edit view" menu, you can create your own user view and
modify it if necessary.
Press softkey "Insert data". The vertical softkey bar changes.
The vertical softkey bar can be used to incorporate the following data
into your user view:
· General machine data
· Channel-specific machine data
· Axis-specific machine data
· Feed spindle drive data
· Main spindle drive data
Position the cursor on the desired data. The selected data is
incorporated in the user view.
Return to the "Edit view" window.
In this window you can label your user view. Entries in the "Text" field
appear in the header, while entries in the "Description" field appear in
the footer of your user view.
The entered text appears in the user view.
The currently selected row is deleted without confirmation.
Using the softkeys "Up" and "Down", it is possible to move the row on
which the cursor is positioned one row up or down.
In this way it is possible to view and change the properties of the
selected entry. In the "Designation" field you can change the name of
the machine data.
In the "Description" field you can label your entries.
