Siemens SINUMERIK 810D User Manual

2
Operator Components/Sequence of Operations 03.04
2.5 Screen la
y
out
2
Ó Siemens AG, 2004. All rights reserved
2-52 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
2.5.3 Program control display
Function
Functions that have been activated are visible in the program control
display (can be set via "Program control", see Subsection 4.6.12). The
functions are displayed irrespective of the selected menu.
SKP
Skip block
Program blocks in which the block no. is preceded by a slash are
skipped when you run the program (e.g. "/N100 ...").
From SW 6.4 you can hide up to 10 program levels (e.g. "/6N100 ..";
the 7th program level is hidden)
References: /PG/, Programming Guide Fundamentals, Chapter 2
SKPn
n = active skip levels
SBL1
Single block with stop after
each machine function block
If this function is active, execution is interrupted after every block that
triggers a function on the machine
(calculation blocks do not cause an interruption).
SBL2
Single block with stop after
each block
If this function is active, the part program blocks are executed as
follows: Each block is decoded separately and execution is interrupted
after every block.
SBL3
Stop in cycle
If this function is active, the part program blocks are executed
individually in the cycle as follows:
Each block is decoded separately and execution is interrupted after
every block. Part program blocks are
• Traversing blocks
• Switching and auxiliary functions
• Blocks generated within the control
(e.g.: blocks inserted by tool radius compensation)
• Thread blocks after retraction
• Thread blocks with dry run feedrate
Thread blocks without dry run feedrate are an exception to this. Here,
execution is only interrupted at the end of the current thread block.
SBL2 can only be selected in the Reset state.
Either SBL1 or SBL2 can be selected!
This function can be activated only in the "Single block" state.
DRY
Dry run feedrate
Traverse movements are performed with the feedrate value set in the
setting data "Dry run feedrate".
This dry run feedrate function replaces the programmed motion
commands.
