9
03.04 "Startup" Operating Area
9.6 HMI
9
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 9-457
Position the cursor on the desired point and perform the settings.
Save
Transfers your settings to system.
9.6.3 Transferring display MD from HMI Embedded
Use When migrating from the HMI component HMI Embedded (PCU20) to
HMI Advanced (PCU50/70) you may like to transfer tried and proven
display machine data from the HMI Embedded configuration to the
HMI Advanced configuration, e.g. for use with ShopMill/ShopTurn.
The following section describes how to proceed for to transfer the
machine data.
Initial situation Display machine data reside on the NCU for HMI Embedded, and on
the hard disk of the PCU50/70 for HMI Advanced.
Display MD
Display MD
HMI-Embedded
NCU1
HMI-Advanced
Case 1
Display MD
NCU1
Netw. drive
Floppy Disk
Display MD
HMI-Advanced
NCU2
Case 2
PCU 50
PCU 50
PCU 20
HMI-Embedded
Handling The transfer consists of two steps:
· Copy the display machine data with HMI Embedded
· Read into the PCU50/70 under HMI Advanced
Case 1 acc. to diagram
On the HMI Advanced system: Services operating area
Transfer display machine data to the display if not yet activated:
Services ® Select data
Select "Display machine data"
OK
Copy display machine data:
Services ® Manage data
Display machine data\BDxxyy.tea
Copy
