4
Machine Operating Area 03.04
4.6 Automatic mode
4
Ó Siemens AG, 2004. All rights reserved
4-148 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
4.6.7 Program editing
Function
As soon as a syntax error in the part program is detected by the
control, program processing is interrupted and the syntax error is
displayed in the alarm line.
You can switch to the program editor and monitor the program run in
a full-screen display. If an error occurs (Stop state), you can edit the
program in the program editor.
Operating sequence
"AUTO" mode is selected in the "Machine" operating area.
It is not possible to overtravel the point of interruption. The feedrate
override switch is active.
The program status is "Stopped" or "Reset".
Correct
program
When you press this softkey, the correction editor is displayed, the
softkey bars change and the softkey "Edit" is highlighted.
If an error occurs, the faulty block is highlighted and can be corrected.
Using editor functions "Overwrite", "Highlight block", "Insert block",
"Go To..." and "Find...", you can edit the program in the correction
block editor.
Program
level +
or
Program
level -
You can toggle between program levels using these softkeys.
Press "Level -" to view the program in which the faulty routine is
called. You can return to the program to be edited by pressing
"Level +". This is only possible if the NC has a correction block.
Cycle Start
After you have corrected the error, you can continue the program run
by pressing "NC Start".
