8.3 Service display
8.3.1 Service overview (from SW 6)
Function
When commissioning digital drives and diagnosing faults, the various
operating states of individual machine axes can be visualized with a
type of traffic light indicator in the "Service overview" display, which
you can open from the "Service display" menu.
Service overview
This overview shows specific enable signals and statuses for each of
the available axes 1 to 31. Up to 6 different states can occur on each
axis:
Columns for machine axes 1 to 31
Software version 6.3
Traffic light indicator states per axis
and higher
Green dot:
The axis is behaving normally
Amber dot:
The axis is not ready
Gray dot:
Does not concern this axis
Red dot:
An alarm is pending for this axis
Dash:
No drive assigned to axis
Hash:
Error reading the data
if e.g. data is missing
Rows with the drive diagnostic functions
Drive enable (terminal 64/63)
Pulse enable (terminal 64/48)
Pulse enable (term. 663 / SI: drive relay)
In software version 6.3
Setup mode (terminal 112)
and higher
PLC pulse enable
NC speed controller enable
DC link status
Enable pulses
Drive ready
Heatsink temperature warning
In software version 6.3
Power section in i2t limitation
and higher
Motor temperature warning
Measuring system 1 active
Measuring system 2 active
