5.7 User data/user variables
(
GUD
,
PUD
,
LUD
)
5
Ó Siemens AG, 2004. All rights reserved
5-252 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
5.7.2 Changing/finding user data/user variables
Operating sequence
User
data
Press softkey "User data".
The "Global user data" window is displayed.
The vertical softkey bar changes.
Global user
data
You can toggle between windows
· "Global user data" (GUD)
Channel-sp
user data
· "Channel-specific user data" and
Program
user data
· "Program user data"
Program-global variables (PUD) and local variables (LUD) are
displayed.
You can scroll up and down in the list using the "Page" keys.
Edit user data
Position the cursor on the user data that you wish to edit and enter a
new value.
New values are automatically accepted.
Search user data
GUD + GUD -
Press softkeys "GUD +" and "GUD - " to scroll through user data from
GUD 1 to GUD 9.
GUD:
The "Select global user data" window is opened. The following values
are permissible:
· 1 = SGUD (Siemens)
· 2 = MGUD (machine manufacturer)
· 3 = UGUD (machine user)
· 4 ... 9 = GD4 ... GD9 (additional, e.g. grinding cycles, etc.)
The selected data are displayed in the "Global user data" window.
Other information
Up to 200 characters can be entered/displayed for GUD of type
String.
