5
"Parameters" Operating Area 03.04
5.2 Tool offsets
5
Ó Siemens AG, 2004. All rights reserved
5-184 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
5.2.2 New tool
Function
If you create a new tool, the associated tool types are automatically
displayed to assist you when you select the tool group.
Operating sequence
Tool
offset
The "Tool offset" window is displayed automatically.
New ...
New
tool
Select softkey "New tool".
The "New tool" window appears on the screen.
As soon as you enter the first characters in the string for the tool
group, for example
· 5xy turning tools
all available tool types in the 5xy group are automatically displayed for
you to select, i.e.
· 500 Roughing tool
· 510 Finishing tool
· 520 Plunge cutter
· 530 Parting tool
· 540 Threading tool
· 550 Steel profile
· 560 Rotary drill (ECOCUT)
· 580 Oriented probe
Enter the digits for your selections via the alphanumeric keypad or
select them from the displayed list.
Abort
No new tool is set up.
OK
A new tool is set up.
The window is closed.
OK + new
tool
Sets up another tool.
The window remains open so that you can set up other new tools.
OK + new
cutting edge
Sets up another cutting edge for the tool you have just set up.
The window remains open.
