Siemens SINUMERIK 810D User Manual

6
"Program" Operating Area 03.04
6.7 Pro
g
ram relationshi
p
in the dual editor
(
from SW 6.4
)
6
Ó Siemens AG, 2004. All rights reserved
6-302 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Find/Go
to...
Find: If the search term is located in the step identifier, the cursor is
positioned on the step. If the search term is not found within a step, a
message is displayed "Search text not found".
Go to: If the block number is located within a step, the cursor is
positioned on the main level or sublevel of the step.
6.7 Program relationship in the dual editor (from SW 6.4)
6.7.1 Views in the dual ASCII editor
Find/Go
to...
View
subroutine
If you are positioned on a subroutine call in the ASCII editor, this
program is loaded to the second editor when you press the "View
subroutine" softkey.
The function is only available in the ASCII editor.
6.7.2 Synchronized view in the dual ASCII editor
Find/Go
to...
Synchr.
wait markers
You can view instruction groups in the ASCII editor. Position the
cursor on a Wait marker instruction in one of the two ASCII editors.
Press the softkey "Synchr. wait markers". This string is searched in
the second editor and displayed at the same height in the window with
the cursor positioned in the first editor. The focus remains in the first
editor. If no wait marker instruction is found together with its brackets,
the next wait marker instruction is displayed in the adjacent window
regardless of the brackets.
