6
"Program" Operating Area 03.04
6.3 Pro
ram main screen
6
Ó Siemens AG, 2004. All rights reserved
6-268 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Horizontal softkeys
Parts
programs
An overview of all part programs (main programs) stored in the
selected directory is displayed.
Sub-
programs
An overview of all subprograms stored in the selected directory is
displayed.
Subprograms are processed in the same way as described for
"Process main programs".
<External
drive>
If external drives are configured, up to three softkeys can be found in
the softkey menu with the configured drive/computer designation. See
softkey assignment below.
Standard
cycles
Select softkey "Standard cycles" to display a list of the cycles that
Siemens has added. See softkey assignment below.
User
cycles
Select softkey "User cycles" to display a list of the user cycles that
you have added.
Manufact.
cycles
Select softkey "Manufacturer cycles" to display a list of the cycles that
have been integrated by the manufacturer.
Clipboard
After pressing the "ETC" key, you can display a list of the programs/
data stored in the clipboard by pressing softkey "Clipboard".
Log
After pressing the "ETC" key and the softkey "Log", you can display
the log of error messages for errors which occurred during "Copy",
"Rename", "Load", etc.
Softkey assignment
If external network drives are configured for the control, the softkeys
for these drives replace the softkeys "Standard cycles", "User cycles"
and "Manufacturer cycles". If you have configured four softkeys, the
fourth one is displayed in the More bar when you press the "ETC" key.
If network drives are configured, the softkeys "Standard cycles", "User
cycles" and "Manufacturer cycles" also appear in the continuation of
the bar after pressing the "ETC" key.
Vertical softkeys
New ...
Creates a new file for a workpiece/part program.
If activated templates exist for the created data type, they are
proposed. If they are accepted, the copy of the template becomes the
created object.
