"Diagnosis" Operating Area 03.04
8.6 Dis
p
la
y
in
g
NC s
y
stem resources
8
Ó Siemens AG, 2004. All rights reserved
8-434 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
8.6 Displaying NC system resources
Function
For the NC areas you can display the system resources (utilization
display) currently being used:
Net and gross runtimes of
· position controller,
· interpolator and
· preprocessing.
Operating sequence
Diagnosis
The "Diagnosis" operating area is selected.
Service
displays
System
resources
NC
Press softkey "Service displays" then "System resources:.
The "NC utilization" screen is displayed.
The following minimum/maximum total data for the servo, IPO cycle
and preprocessing are displayed:
· Net runtime in ms
· Gross runtime in ms
· Level of the IPO buffer in percent
· Total capacity utilization in percent
Stop
Start
The display update can be halted with the softkey "Stop", the
displayed values are updated again with the softkey "Start".
