5
03.04 "Parameters" Operating Area
5.2 Tool offsets
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-185
5.2.3 Display tool
Function
You can select tools that you have set up and access their tool
compensation data.
Operating sequence
Tool
offset
The "Tool offset" window is displayed automatically.
If the "Parameter" area has already been selected, the window and
the last tool selected when the area was exited are displayed.
The tool offset data of the current tool are displayed immediately. If no
tool has yet been selected, the data of the first tool are shown
together with its first D number.
If no tools are available in the area, a message is output.
T No.
+
T No.
–
Select the set up tools.
Other information
Input of the geometry and wear data of the tool can be disabled using
the keyswitch.
