03.04 "Program" Operating Area
6.10 Mana
e
ro
rams
6
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 6-347
6.10.6 Load/unload program
Function
Programs can be stored in the NC memory ("Load") and then erased
from it again ("Unload") after execution. This prevents the NC memory
from being overloaded unnecessarily.
Operating sequence
Position the cursor on the program to be loaded.
Download
HD->NC
The highlighted program is loaded from the hard disk to the NC
memory.
The selected program is deleted on the hard disk.
See also Chapter "Job list".
Alter
enable
If enable is set "(X)", the program can be executed.
Upload
NC->HD
The highlighted program is uploaded from the NC memory to the hard
disk.
The selected program is deleted in the NC memory.
Other information
Programs which have been loaded to the NC memory are
automatically marked with an "(X)" (in the "Loaded" column) in the
program overview.
If the file is located both in the HMI and in the NC, the identifier "X" is
only removed when the files are no longer identical.
If the files have different time stamps or are of different lengths, the
identifier is "!X!".
