03.04 "Parameters" Operating Area
5.6 Work offset
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-249
5.6.6 Display active work offset external
Function
The active, external work offsets can be displayed.
Values cannot be edited in this display.
Operating sequence
Work
offset
Go to...
Select softkeys "Work offset" and "Go to ...".
The vertical softkey bar changes.
External
WO
The "External WO" window is opened.
5.6.7 Display sum of the active work offsets
Function
The sum of the active work offsets from part program can be
displayed.
Values cannot be edited in this display.
Operating sequence
Work
offset
Go to...
Select softkeys "Work offset" and "Go to ...".
The vertical softkey bar changes.
Sum of
WO
The "Sum of WO" window is opened.
The sum of work offsets is calculated in the following way:
Sum WO = active settable WO + active programmable WO
The values can be changed only in the "Settable work offsets" menu.
(see Section "Settable work offsets" menu)
