Siemens SINUMERIK 810D User Manual

8
"Diagnosis" Operating Area 03.04
8.5 Selectin
g
/creatin
g
o
p
erand screens for PLC status
8
Ó Siemens AG, 2004. All rights reserved
8-432 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
8.5 Selecting/creating operand screens for PLC status
Function
You can save the operands entered in the "PLC status" window to a
file or read in a back-up list of operands.
Operating sequence
Diagnosis
or
Start-
up
The operating area The operating area "Start-up" is selected.
PLC
Select softkey "PLC".
The horizontal and vertical softkey bars change.
File
functions
Select softkey "File functions".
The vertical softkey bar changes.
Enter the name of the file in which you wish to save the operands.
You can select existing back-up files from a list.
All the following functions refer to the file name entered:
Delete
The selected operand back-up file is deleted.
Save
The selected operands are saved to the specified file.
Load
The selected operand file is loaded to the "PLC status" window for
processing.
Error
log
If errors occur during transfer of the machine data, these are entered
in an error log.
The error log is transfer-specific, i.e. it is cleared before each new
transfer.
Editor
The ASCII editor is called with the selected file.
You can now edit the operand back-up file.
