6
"Program" Operating Area 03.04
6.10 Mana
e
ro
rams
6
Ó Siemens AG, 2004. All rights reserved
6-348 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
If you want to "load/unload" a workpiece directory and a job list with
the name of the directory exists in the directory, then this job list is
processed.
If a job list does not existing, all the files in that directory are
loaded/unloaded (RAM of NC might overflow!).
6.10.7 Load/unload program
Function
You can reorganize programs and files in the "program overview"
using the "Manage programs" function:
New ... Select new workpiece/part program
Copy/insert Copy directories and files
Delete Delete workpieces and files
Rename Rename file and data type
Modify enable Enable each workpiece/part program in the
program overview or not.
Operating sequence
Manage
programs...
In the "Program overview" dialog box press the horizontal softkey
"Manage programs...". Active functions are indicated by softkeys in
which the text appears on a black background. Inactive softkeys are
grayed out.
New ...
Press the "New ..." softkey to select a new workpiece or part program.
The "interactive programming" window is opened and the cursor is
positioned in the input field for the name of the new directory. Enter
the new name of the program. The file type is assigned automatically.
The display also shows whether or not a template exists.
Default
You can choose between interactive programming and the text editor.
The more frequent choice, file editing with "interactive programming",
is the default setting. Alternatively, you can use the text editor to edit
files.
Confirm your input with the "Input" key.
