Siemens SINUMERIK 810D User Manual

5
03.04 "Parameters" Operating Area
5.5 Settin
g
data
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-235
5.5.2 Jog data
Function
The feedrates must be specified in the unit determined by the G
function.
G function
G94 Feedrate in mm (inch)/min
G95 Revolutional feedrate in mm (inch)/rev
JOG feedrate
Feedrate value in JOG mode
Continuous JOG
· JOG mode: The axis moves as long as the key is pressed.
· Continuous mode: The axis begins to move when the key is
pressed once and continues until:
- The key is pressed again,
- NC Stop,
- Reset,
- Software/hardware limit switch.
Variable increment
Increment value for Jog variable increment
The following data are displayed only if a spindle is configured:
JOG spindle speed
Spindle speed in Jog mode
Spindle
Jog data for the master spindle:
· Spindle no. Name of leading spindle
· Direction of rotation: Direction of rotation of leading spindle
· Spindle speed: Speed of the master spindle in Jog mode
Operating sequence
Setting
data
Select softkey "Setting data".
The vertical softkey bar changes.
Jog data
Select softkey "Jog data".
The "Jog data" window is opened.
