Siemens SINUMERIK 810D User Manual

4
03.04 Machine Operating Area
4.5 MDI mode
4
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 4-135
4.5 MDI mode
4.5.1 Function and main screen
In "MDI" (Manual Data Input) mode, you can write part programs
block by block and execute them. You can transfer the required
motions as single part program blocks to the control using the
operator panel.
The control processes the entered program blocks when you press
the "NC Start" key.
Caution
The same safety interlocks must be applied as used in fully automatic
operation. The same preconditions must be fulfilled as for fully
automatic operation.
The automatic functions (traverse blocks) are active in "MDI" mode.
Teach In
The functions associated with "Jog" are active in submode "Teach In"
and can be accessed via an MCP key. You can therefore create and
store a program in the input and manual modes by alternating
between "MDI" and "Teach In".
You can use the editor to edit the program blocks in the MDI window.
You can view blocks that have already been processed by paging
upwards.
Blocks that have already been executed can only be edited in the
Reset state.
Further blocks can be added with "Input".
Blocks can be input and executed only with the channel in the
"Channel Reset" or "Channel interrupted" state.
The program generated in MDI mode can be stored
· in the part programs directory (MPF.DIR)
