Siemens SINUMERIK 810D User Manual

4
03.04 Machine Operating Area
4.6 Automatic mode
4
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 4-145
4.6.5 Executing programs from the hard disk
Function
If a program requires more memory than the NC can provide for
execution, then it can be loaded continuously from the hard disk.
Operating sequence
The "Machine" operating area is selected.
Program
overview
The "Program overview" is open.
The vertical softkey bar changes. Select the program you wish to
execute with the cursor (enable (x) must be set).
Execute fr.
hard disk
The highlighted program is loaded continuously to the NC memory
during execution.
Cycle Start
Press "NC Start"
.
The program remains stored on the hard disk while the "Execute from
hard disk" function is in progress.
External
programs
The "External programs" window is opened.
The "Status" field indicates what percentage of the program has been
loaded from the hard disk.
Other information
Programs which are executed from the hard disk are marked with
"EXT" in the program overview.
The identifier "EXT" does not disappear until a different part program
is selected in this channel.
From SW 6.2:
If the programs are executed from the hard disk, the 3-block display
(softkey program run) or the larger multi-block display (softkey
program blocks) can be selected during automatic operation. The
setting made applies for the single block or NC stop status.
