Siemens SINUMERIK 810D User Manual

8
03.04 "Diagnosis" Operating Area
8.3 Service dis
p
la
y
8
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 8-417
8.3.7 Action log
Action
log
An existing action log can be displayed. For additional information on
configuring the contents of the action log, see Installation and Start-
Up Guide HMI Advanced (IM4).
8.3.8 Version
Function
The version data of the installed system software are output in the
Version display.
You can sort and save the version displays. Version displays saved
as ASCII files can be edited as required or sent to the hotline in the
event of an error.
Operating sequence
Service
displays
Press softkey "Service displays".
The horizontal softkey bars change.
Version
Open the "Version" window in the "Service displays" menu.
The following softkeys are displayed:
NCU
version
"NCU version" for the version data of the NCU and
HMI
version
"HMI version" for the version data of the HMI.
Option for
Compile cycles
If "compile cycles" are available on the NCK, the version is displayed.
Cycle
version
"Cycle version" version data for each of the cycle packages (SW 6.3
and higher)
Definitions
"Definitions" the version data for definitions
Use the "Page" keys to scroll up and down.
