03.04 "Diagnosis" Operating Area
8.5 Selectin
g
/creatin
g
o
p
erand screens for PLC status
8
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 8-433
8.5.1 File functions
Function
You can use the file functions to manage operand screens.
Operating sequence
Diagnosis
The "Diagnosis" operating area is selected.
PLC status
Press softkey "PLC status".
The first operand screen form appears.
The vertical softkey bar changes.
File
functions
Select softkey "File functions".
The "File functions" window opens.
Enter the file name of the desired operand screen form or
position the cursor on the desired operand screen form in the list.
Delete
The selected operand screen form is deleted.
Save
The current contents of the PLC status are saved in the selected
operand screen form.
Load
The contents of the selected operand screen form are loaded to the
PLC status.
Other information
The operand screen forms are ASCII files.
