6
03.04 "Program" Operating Area
6.4 Edit
ro
rams
6
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 6-269
Load
HD->NC
The highlighted program (or programs) is (are) loaded from the hard
disk to the NC memory.
Unload
NC->HD
The highlighted program is unloaded from the NC memory to the hard
disk.
Simulation
With the function "Simulation" you can display axis movements
graphically and simulate the results of machining on the screen. See
also 6.6.
Manage
programs...
With the softkey "Manage programs" you can manage the functions
"New", "Copy", "Insert", "Delete", "Rename" and "Enable".
Select
The name of the selected workpiece is displayed on the screen in field
"Program name" at the top. The program is also loaded and selected
for processing.
<<
When you branch to a workpiece, softkey "<<" automatically appears
to allow you to return to the main menu.
6.4 Edit programs
6.4.1 Text editor
Chapter 2, "General operating sequences"
· The editor displays only the characters which can be input via the
operator panel front keyboard.
· A part program opened by the editor cannot be simultaneously
started in the NC (enable is canceled); an alarm (14011) is
indicated in this case. If the control is switched off while the editor
is open, the enable might have to be set manually.
· When you exit the editor after editing cycles in the NC and if these
cycles are also stored in the Flash File System, then an activity
symbol (fan symbol) is displayed while the data is being copied
into the Flash File System. See also Subsection 6.2.1 "HMI".
