5
"Parameters" Operating Area 03.04
5.5 Settin
g
data
5
Ó Siemens AG, 2004. All rights reserved
5-240 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Other information
Data can be edited or not depending on the active access protection
level.
5.5.7 Protection zones
Function
The "Protection zones" function allows you to protect various
elements on the machine, your equipment or the machined workpiece
against incorrect axis motions. You can view up to 10 programmed
protection zones in levels G17, G18 and G19.
For further information about protection zones, please refer to /PGA/,
Programming Guide, Advanced.
Operating sequence
Setting
data
Select softkey "Setting data".
The vertical softkey bar changes.
Protection
zones
Select softkey "Protection zones".
The "Working area limitations and protection zones" window opens.
The vertical softkey bar changes again.
Protection
zone +
Protection
zone -
Select softkey "Protection zone +" or "Protection zone -".
Up to 10 protection zones are displayed in succession.
Select the plane in which the relevant protection zone is located:
G17
· Plane G17 (X,Y; Infeed direction Z)
G18
· Plane G18 (Z,X; Infeed direction Y)
G19
· Plane G19 (Y,Z; Infeed direction X)
