Siemens SINUMERIK 810D User Manual

6
03.04 "Program" Operating Area
6.9 Pro
g
ram simulation
6
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 6-323
6.9.2 Simulation settings
"Settings..." menu
Only accessible from the RESET or STOP state of the simulation (e.g.
single block mode).
Other settings can only be displayed/hidden if you enter a valid
password via the Options softkey.
Load
standard
Options
on/off
or
Options
on/off
Load manufacturer-specific default settings
(See data management: \DP.DIR\SIM.DIR\SIMINI_M.COM for milling
or
SIMINI_T.COM for turning and differential files in the \USER directory.
Display/hide optional setting parameters in the current window,
(Initial setting is options off)
Change
default
The default values can be modified according to the manufacturer's
needs if a valid password is entered.
The changes to the manufacturer-specific default set values in files
"SIMINI_M.COM" and "SIMINI_T.COM" are used as differential
parameters in the files "DPMWP.INI" and "DPTWP.INI" in the \USER
directory and taken into account for all new workpieces.
Downtime
settings
With the correct password, you can set the desired computation mode
for secondary times and selectively define estimated secondary times
for the NC functions T, S, M and H.
· Settable parameters: See Section "Settings secondary times"
