Machine Operating Area 03.04
4.6 Automatic mode
4
Ó Siemens AG, 2004. All rights reserved
4-142 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
4.6.2 Program Overview
Function
After selection of a workpiece or program overview, individual
workpieces or programs can be enabled or disabled for execution.
Operating sequence
"AUTO" mode is selected in the "Machine" operating area.
The appropriate channel is selected.
The channel is in reset state.
The workpiece/program to be selected is in the memory.
Program
overview
An overview of all workpiece directories/programs that exist is
displayed.
Position the cursor on the desired workpiece/program.
Vertical softkeys
Select the workpiece/program for execution:
Selection
The name of the selected workpiece is displayed on the screen in field
"Program name" at the top. The program is also loaded and selected
for processing.
Alter
enable
The selected workpiece/program is enabled (X) or disabled (no "X").
A selection can only be made when the workpiece/program is
enabled.
Explanation of other softkeys:
All programs of a particular type are displayed via the horizontal
softkeys:
Work-
pieces
Display of all workpiece directories
Part
programs
Display of all existing part programs
