7
"Services" Operating Area 03.04
7.5 O
p
eration
7
Ó Siemens AG, 2004. All rights reserved
7-384 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Operating sequence
Data in
The "Programs/Data" file tree is displayed.
The vertical softkey bar changes.
Mark the file into which you wish to read the archive.
Select the source area (see title in window):
RS-232
· RS-232 interface
Interface is made ready to receive. (1st RS-232 interface)
PG
· Programming device (2nd RS-232 interface)
Diskette
· Diskette drive: Shows the contents of the diskette. Select the
archive you wish to import.
Archives
· Opens the "Archives" directory on the hard disk. Select the archive
you wish to import.
NC card
· The contents of the archives directory on the NC card are
displayed.
Select the archive you wish to import.
Users with access authorization to level 3 and higher can access this
softkey. It is displayed only if archive _N_ORIGINAL_ARC is stored
on the NC card.
7.5.4 Reading out data
Function
Creating archives:
With the "Data out" function, the source area (see title in window) for
data transmission is the displayed directory tree.
Possible target areas are:
· A device connected to the RS-232 interface (e.g. PC)
· A diskette drive
· "Archives" directory on hard disk
· Free memory areas on the NC card
Operating sequence
Data out
The "Programs/Data" file tree is displayed.
The vertical softkey bar changes.
