03.04 Operator Components/Sequence of Operations
2.4 Machine control
p
anel ke
y
s
2
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 2-41
Auto
*
Automatic
Control of machine through automatic execution of programs.
Inc keys
You can activate the Inc functions in conjunction with the following
modes:
· "JOG" operating mode
· "MDI/Teach In" operating mode
VAR
Inc Var
Incremental feed variable
Incremental traverse with variable increment size (see Parameters
operating area, setting data).
1 10 100
1000 10000
Inc
Incremental feed
Incremental traverse with preset increment size of 1, 10, 100, 1000,
10000 increments.
The increment value is evaluated according to the setting in the
machine data.
Machine functions
MDI
Teach In
Teach In
Creation of programs in interactive mode with the machine in
"MDI" mode.
JOG
Repos
Repos
Repositioning
Reposition, re-approach contour in "JOG" mode.
JOG
Ref Point
Ref
Approaching a reference point
Approach the reference point (Ref) in "JOG" mode.
