9
"Startup" Operating Area 03.04
9.6 HMI
9
Ó Siemens AG, 2004. All rights reserved
9-454 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
9.6.2 System settings
Function
System
settings
This softkey provides access to settings for inquiry windows, file tree
display and screen representation of the Machine, Program and
Services operating areas.
File
display
You can set the file tree display for the Services, Machine and
Program operating areas.
The following columns can be selected:
· Type (Extension)
· Loaded
· Length
· Access prot.
· Date
· Clock
· Enabling of
· Max. display levels (branch to directory trees,
max. 7)
· Max. name length (max. 25 characters)
Your settings are automatically displayed in the "Forecast" window.
Inquiry
Request confirmation before
- Deleting data/programs,
- Deletion of directories,
- File overwrite.
Symbols
Here you can define whether keys must be represented as symbols or
as text in HMI displays.
Example: Operator panel front in US layout ,
E.g. the selection key as symbol (),
as text
Select
.
