8.3.3 Service drive
Function
The information contained in the "Service drive" display is used to
· check the status of the enable and control signals (e.g. pulse
enable, drive enable, motor selection, setpoint parameter set)
· check the status of the FDD/MSD operating modes (e.g. setup
mode, parking axis)
· display temperature warnings
· check the current setpoint/actual-value display (e.g. position
actual-value measuring system ½, speed setpoint, speed actual
value)
· check the drive status
· display the current ramp-up phase
· display the group error message (message status class 1)
· display the status messages of the drive (e.g. threshold torque not
reached, actual speed = set speed)
References: /FB/, Description of Functions D1, Diagnostics Tools
Operating sequence
Service
displays
Select the menu headed "Service displays".
The softkey bars change. The vertical softkeys are context-sensitive
according to the service display. The softkeys in the horizontal menu
bar allow you to select the corresponding service displays.
Service
drive
The "Service drive" window displays information about the axis drive
together with axis name and number.
You can page up and down with the "Page" keys.
Vertical softkeys for axis selection
Drive
+
Drive
-
The service values of the next (+) and the previous (-) drive are
displayed.
Direct
selection...
The vertical softkey "Direct selection" in the window of the same name
allows you to select an axis directly from the list of available axes.
