"Parameters" Operating Area 03.04
5.6 Work offset
5
Ó Siemens AG, 2004. All rights reserved
5-248 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
The following values are displayed:
· Actual value of MCS and settable zero system
· Overlaid movements
· DRF offsets
· Work offsets external
· Sum of the work offsets; calculated from the basic, settable and
programmable work offsets
(corresponds to the table "Change active ...")
· Data of the active tool (T number, D number with reference to the
plane G17, lengths, radius)
· WCS actual value.
Other information
The active work offset must be changed only when the NC program is
stopped. Changes are updated immediately. The work offset values in
the display are updated cyclically.
5.6.5 Display active programmable work offset
Function
The active, selected programmable work offsets (from part program or
MDI) can be displayed.
Values cannot be edited in this display.
Operating sequence
Work
offset
Go to...
Select softkeys "Work offset" and "Go to ...".
The vertical softkey bar changes.
Active
progr. WO
The "Active progr. WO" window opens.
