8
"Diagnosis" Operating Area 03.04
8.3 Service dis
p
la
y
8
Ó Siemens AG, 2004. All rights reserved
8-418 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
8.3.9 Sorting and saving version information
There are various sorting functions for the following version lists:
· HMI version
· Cycle version
· Definitions
Sort
In the left-hand part of the pane for sorting, you can select a sort
criterion from the column designations in the list by pressing the
Select key. In the right-hand pane you can choose from descending
and ascending sorting sequence for the selected sort criterion.
Save
versions
The sorted and unsorted version displays of the display area are
saved as follows for HMI versions:
Range Target File
HMI version
Services ®Diagnostics\LogFiles
HMI.COM
How to save the other areas is described in the area descriptions.
Specific features
of HMI versions
Software objects are displayed in red if they are not unambiguous
(e.g. several executable programs with the same name in different
directories) or,
if the entry in the registry file does not match the actual storage
location of an object.
A language-independent message is displayed in the message line:
1: <actual registry entry> or
1: - , if there is no registry entry or
2 for al other files under a different path
The dialog messages are also written to the log file.
The checking procedure takes place when the respective version
display is first accessed.
