03.04 "Services" Operating Area
7.4 RS-232 interface
p
arameters
7
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 7-375
Saving RS-232 interface
settings
In HMI Advanced software version 6.2 or later, RS-232 interface
settings can be stored in specific files in the RS-232.DIR directory.
The parameters in a file can be assigned to one of the interfaces.
Additional functions are planned for managing/updating these files.
See Setting the RS-232 interface.
7.4.1 Interface parameters
Parameters for archiving
with PG/PC
Default: RS-232-C PG/PC
Interface: COM2
Protocol: RTS/CTS
Parity:
Stop bits: 1
Data bits: 8
Baud rate: >= 9600
Archive format: Binary format (PC format)
This setting allows files in SINUMERIK 840D PC format to be
archived and imported.
"Stop with end of transmission character" must not be selected for
transmission of MSD and FDD files.
Other settings are possible with ASCII data. They must correspond to
those on the programmer. Cable 6FX 2002-1AA01- is used for this
purpose.
Parameters for DIN
programs
Default: RS-232-C user
Interface: COM1
Protocol: RTS/CTS
Parity: None
Stop bits: 1 ¨ With leader and trailer
Data bits: 8 ý Stop with end of transmission character
Baud rate: 9600
Archive format: Punched tape with ... Time monitoring (sec.): 04
With this setting, programs conforming to DIN (beginning with %) are
read in or out.
