6.9.4 Display and colors
General attributes
Settings
Display and
colors...
Setting the general properties of the simulation graphics:
Rapid traverse dashed line
Alternatively, rapid traverse as a full line, as used for feedrate
Scale at edge of window
Alternatively, as scale on the coordinate axes
Path labels
Under "path label management" offers various possibilities for
displaying program labels, which have been inserted freely to identify
specific points in the NC program (observe label syntax), as path
labels at the corresponding point in the simulation graphics and then
storing the associated graphic model in the buffer.
Program labels can also be used to mark program sections which can
then be included by the central time recording facility (see ..\
Downtime settings \ Time calculation mode \ In sections with labels).
Path labels are specified in "Channel/spindle" as delimiter for section
by section simulation in the same or different channels.
You can save section models and use a search run to start again at
that point without needing to repeat the preceding sections.
Use of color palettes
- Select a color with the cursor keys and press the
Select key. The color of the focus frame changes.
- Use the cursor keys to select the object and press the
Select key again. The object displays the selected color.
General colors
In addition to the standard VGA colors, the color elements black and
transparent to hide graphic elements are available in the color palette.
Color selection option for background, blank, axis intersection, tool
holder and tool edge.
