Mediant 3000

59.2.4 Mediant 3000 DSP Template Mix Feature

The device can operate (and be loaded) with up to two DSP templates. The channel

capacity per DSP template is approximately 50%, with alignment to the number of DSP's

present in the device.

Table 59-5: Template Mix Feature Channel Capacity

DSP Template Mix Number of Channels

1 (AMR) / 2 (EVRC) 960

1 (AMR) / 5 (EVRCB) 768

1 (AMR) / 7 (iLBC) 864

Default Chapter3
