AudioCodes Mediant 3000 User Manual

Version 7.0 391 Mediant 3000
User's Manual 20. Coders and Profiles
20.4 Configuring IP Profiles
The IP Profile Settings table lets you configure up to 10 IP Profiles. An IP Profile is a set of
parameters with user-defined settings relating to signaling (e.g., SIP message terminations
such as REFER) and media (e.g., coder type). An IP Profile can later be assigned to
specific IP calls (inbound and/or outbound). Thus, IP Profiles provide high-level adaptation
when the device interworks between different IP entities, each of which may require
different handling by the device. This can include, for example, transcoding or even
transrating (of packetization time). For example, if a specific IP entity uses the G.711 coder
only, you can configure an IP Profile with G.711 for this IP entity.
To use your IP Profile for specific calls, you need to assign it to any of the following:

IP Groups - see ''Configuring IP Groups'' on page 343

Gateway application: Tel-to-IP routing rules - see Configuring Tel-to-IP Routing Rules
on page
496

Gateway application: IP-to-Tel routing rules - see Configuring IP-to-Trunk Group
Routing Rules on page
505
For the Gateway application: The device selects the IP Profile as follows:

If you assign different IP Profiles (not default) to the same specific calls in all of the
above-mentioned tables, the device uses the IP Profile that has the highest preference
level (as set in the 'Profile Preference' parameter). If these IP Profiles have the same
preference level, the device uses the IP Profile that you assigned in the IP Group
table.

If you assign different IP Profiles to all of the above-mentioned tables and one table is
set to the default IP Profile, the device uses the IP Profile that is not the default.
Many of the parameters in the IP Profile table have a corresponding "global" parameter.
For calls that are not associated with any IP Profile, the settings of the "global" parameters
are applied.
Note: IP Profiles can also be implemented when using a Proxy server (when the
AlwaysUseRouteTable parameter is set to 1).
The following procedure describes how to configure IP Profiles through the Web interface.
You can also configure it through ini file (IPProfile).
 To configure an IP Profile:
1. Open the IP Profile Settings table (Configuration tab > VoIP menu > Coders and
Profiles > IP Profile Settings).
2. Click Add; the following dialog box appears:
