AudioCodes Mediant 3000 User Manual

Version 7.0 753 Mediant 3000
User's Manual 51. VoIP Status
51.9 Viewing Call Routing Status
The Call Routing Status page provides you with information on the current routing method
used by the device. This information includes the IP address and FQDN (if used) of the
Proxy server with which the device currently operates.
 To view call routing status:

Open the Call Routing Status page (Status & Diagnostics tab > VoIP Status menu >
Call Routing Status).
Figure 51-8: Call Routing Status Page
Table 51-4: Call Routing Status Parameters
Parameter Description
Call-Routing Method
 Proxy/GK = Proxy server (Proxy Set) is used to route calls. For
configuring Proxy Sets, see ''Configuring Proxy Sets'' on page 355.
 Routing Table = Calls are routed using the routing table:

Gateway calls: Tel-to-IP Routing table (Configuring Tel-to-IP
Routing Rules on page
496)

SBC calls: SBC IP-to-IP Routing table (Configuring SBC IP-to-IP
Routing Rules on page 603)
IP Address
 Not Used = Proxy server isn't defined.
 IP address and FQDN (if exists) of the Proxy server with which the
device currently operates.
State
 N/A = Proxy server isn't defined.
 OK = Communication with the Proxy server is in order.
 Fail = No response from any of the defined Proxies.
