User's Manual 454 Document #: LTRT-89730
Mediant 3000
22.9 Redirect Number and Calling Name (Display)
The following tables define the device's redirect number and calling name (Display) support
for various ISDN variants according to NT (Network Termination) / TE (Termination
Equipment) interface direction:
Table 22-2: Calling Name (Display)
NT/TE Interface DMS-100 NI-2 4/5ESS Euro ISDN QSIG
NT-to-TE
Yes Yes Yes Yes Yes
TE-to-NT
Yes Yes Yes No Yes
Table 22-3: Redirect Number
NT/TE Interface DMS-100 NI-2 4/5ESS Euro ISDN QSIG
NT-to-TE
Yes Yes Yes Yes Yes
TE-to-NT
Yes Yes Yes
Yes*
Yes
* When using ETSI DivertingLegInformation2 in a Facility IE (not Redirecting Number IE).
22.10 SDH / SONET Configuration
Note: This section is applicable only to PSTN STM-1 / OC-3 ports on the TP-6310
blade.
The device supports STM-1 and OC-3 optical fiber transmission modes. Optical fiber
transmission is configured using the PSTNTransmissionType parameter (set to 1) and the
fiber mode is defined using the SdhFbrGrp_SdhSonetMode parameter (set to 1 for STM-1,
or 2 for OC-3). The device supports Automatic Protection Switch (APS) for these
interfaces.
STM-1 interface: provides short range Synchronous Digital Hierarchy (SDH) STM-1
interface compliant with ITU-T G.707 and ITU-T G.957. The interface operates at
155.52 Mbps over a single-mode fiber span. The device supports VC-4 payload at the
STM-1 signal level. The device supports the asynchronous VC-12 mapping (mapping
of E1s into VC12s and multiplexing of 63 VC12 into an STM-1 frame).
Relevant parameters:
• PSTNTransmissionType - set to 'Optical SONET or SDH' (1).
• SDHFbrGrp_SDHSONETMode - set to 'STM1' (1)
• SDHFbrGrp_Mapping_Type - set to 'Asynchronous TU12 and E1' (1)
OC-3 interface: provides short range SONET OC-3 interface compliant to GR-253-
CORE and ANSI T1.105. The interface operates at 155.52 Mbps over a single-mode
fiber span. The following mapping types in OC-3 are supported:
• Asynchronous VT1.5 (DS1 > VT1.5 > STS-1 > OC3) - mapping of T1s into
VT1.5s and multiplexing of 84 VT1.5 into an OC-3 frame
• Byte-synchronous VT1.5 (DS1 > VT1.5 > STS-1 > OC3)
• Asynchronous mapping of DS3 in STS1, DS3 channelized to DS1s (DS1 > DS3 >
STS-1 > OC3)
