AudioCodes Mediant 3000 User Manual

User's Manual 954 Document #: LTRT-89730
Mediant 3000
Parameter Description
[PlayDTMFduringHold]
Determines whether the device sends DTMF signals (or DTMF SIP INFO
message) when a call is on hold.
 [0] = (Default) Disable.
 [1] = Enable - If the call is on hold, the device stops playing the Held
tone (if it is played) and sends DTMF:

To Tel side: plays DTMF digits according to the received SIP
INFO message(s). (The stopped held tone is not played again.)

To IP side: sends DTMF SIP INFO messages to an IP destination
if it detects DTMF digits from the Tel side.
58.10.5.5 Call Transfer Parameters
The call transfer parameters are described in the table below.
Table 58-49: Call Transfer Parameters
Parameter Description
Enable Transfer
[EnableTransfer]
Enables the Call Transfer feature.
 [0] Disable
 [1] Enable = (Default) The device responds to a REFER message with
the Referred-To header to initiate a call transfer.
Notes:
 To use call transfer, the devices at both ends must support this option.
 To use call transfer, set the parameter EnableHold to 1.
Transfer Prefix
[xferPrefix]
Defines the string that is added as a prefix to the transferred/forwarded
called number when the REFER/3xx message is received.
Notes:
 The number manipulation rules apply to the user part of the Refer-To
and/or Contact URI before it is sent in the INVITE message.
 The parameter can be used to apply different manipulation rules to
differentiate transferred / forwarded number from the originally dialed
number.
Transfer Prefix IP 2 Tel
[XferPrefixIP2Tel]
Defines the prefix that is added to the destination number received in the
SIP Refer-To header (for IP-to-Tel calls). The parameter is applicable to
CAS blind transfer modes, i.e., LineTransferMode = 1, 2 or 3, and
TrunkTransferMode = 1 or 3 (for CAS).
The valid range is a string of up to 9 characters. By default, no value is
defined.
Note: The parameter is also applicable to ISDN Blind Transfer, according
to AT&T Toll Free Transfer Connect Service (TR 50075) “Courtesy
Transfer-Human-No Data”. To support this transfer mode, you need to
configure the parameter XferPrefixIP2Tel to "*8" and the parameter
TrunkTransferMode to 5.
Enable Semi-Attended
Transfer
[EnableSemiAttendedTra
nsfer]
Determines the device behavior when Transfer is initiated while in Alerting
state.
 [0] Disable = (Default) Send REFER with the Replaces header.
 [1] Enable = Send CANCEL, and after a 487 response is received,
send REFER without the Replaces header.
