Version 7.0 603 Mediant 3000
User's Manual 33. Routing SBC
To configure a Message Condition rule:
1. Open the Message Condition table (Configuration tab > VoIP menu > SBC >
Routing SBC > Message Condition Table).
2. Click Add; the following dialog box appears:
Figure 33-3: Message Condition Table - Add Row Dialog Box
3. Configure a Message Condition rule according to the parameters described in the
table below.
4. Click Add.
An example of configured Message Condition rules is shown in the figure below:
Figure 33-4: Example of Configured SIP Message Conditions
Index 0: Incoming SIP dialog that is classified as belonging to a User-type IP Group.
Index 1: Incoming SIP dialog that contains a SIP Via header.
Index 2: Incoming SIP dialog with 101 as the user part in the SIP From header.
Table 33-2: Message Condition Table Parameter Descriptions
Parameter Description
Index
[ConditionTable_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
[ConditionTable_Name]
Defines a brief description of the Condition rule.
Condition
[ConditionTable_Conditio
n]
Defines the Condition rule of the SIP message.
The valid value is a string.
Note: User and host parts must be enclosed in single quotes.
33.3 Configuring SBC IP-to-IP Routing
The IP-to-IP Routing table lets you configure up to 200 SBC IP-to-IP routing rules.
Configuration of IP-to-IP routing rules includes two areas:
